WAVE 110i 2018 · E-6 CLUTCH (F.C.C)
Tap a number on the diagram to see the parts. Swipe sideways to see the full diagram.
All parts on page E-6
- 1 COVER, RIGHT CRANKCASE 11330-KWB-600Qty per bike: 1
- 2 HOLDER, OIL TEMPERATURE SENSOR WIRE 11346-KTR-940Qty per bike: 2
- 3 GASKET, RIGHT CRANKCASE COVER 11394-KWB-920Qty per bike: 1
- 4 CLIP, PISTON PIN, 13 mm 13115-GN5-910Qty per bike: 1
- 5 DIPSTICK, OIL LEVEL 15651-K90-V00Qty per bike: 1
- 6 ARM, CLUTCH LIFTER 22810-KTL-740Qty per bike: 1
- 7 PLATE, CLUTCH CAM 22823-KWW-740Qty per bike: 1
- 8 SPRING, CLUTCH LIFTER CAM PLATE 22825-KWW-740Qty per bike: 1
- 9 CLUTCH LIFTER PLATE ASSY 22830-KWW-740Qty per bike: 1
- 10 BOLT, CLUTCH ADJUSTING 22846-KPH-901Qty per bike: 1
- 11 BEARING SET, CLUTCH LIFTER 22860-KWW-740Qty per bike: 1
- 12 WASHER, 8 mm 90485-040-000Qty per bike: 1
- 13 OIL SEAL, 13.8x24x5 91202-KRS-971Qty per bike: 1
- 14 O-RING, 8 mm 91303-001-010Qty per bike: 1
- 15 O-RING, 18x3 91307-035-000Qty per bike: 1
- 16 NUT, HEX, 8 mm 94030-08000Qty per bike: 1
- 17 PIN, DOWEL, 8x14 94301-08140Qty per bike: 2
- 18 BOLT, FLANGE, 6x40 96001-06040-00Qty per bike: 10
